RG/QR series

HIWIN Linear Guide

RG/QR series
Structure of the RG/QR series
○ 4-row recirculation roller bearing guide
○ 45° contact angle
○ Ball retainers prevent the rollers from falling out when the block is removed
○ Various sealing variants depending on the field of application
○ 6 options for connecting grease nipple and lubrication adapter
○ SynchMotion™ technology (QR series)

Advantages
○ Zero play
○ Interchangeable
○ Very high load ratings
○ Very high rigidity
○ Low displacement forces even with high preload

Additional advantages of QR series
○ Improved synchronous performance
○ Optimized for higher travel speeds
○ Extended lubrication intervals
○ Less running noise
