EG/QE series

HIWIN Linear Guide

EG/QE series
Structure of the EG/QE series
○ 4-row recirculation ball bearing guide
○ 45° contact angle of ball tracks Z
○ Ball retainers prevent the balls from falling out when the block is removed
○ Various sealing variants depending on the field of application
○ 6 options for connecting grease nipple or lubrication adapter
○ SynchMotion™ technology (QE series)

Advantages
○ Zero play
○ Interchangeable
○ High accuracy
○ High loading capacity in all loading directions
○ Low friction losses even with preload thanks to optimized ball tracks and 2-point contact

Additional advantages of QE series
○ Improved synchronous performance
○ Optimized for higher travel speeds
○ Extendes lubrication intervals
○ Less running noise
